WSM-200A
| Model | WSM-200A | WSM-160C |
| Function | TIG/MMA | TIG/MMA |
| Output Current (A) | 10~200A @ TIG 30~170A @ MMA | 10~160A @ TIG 30~150A @ MMA |
| Input Voltage (V) | single phase 230V +/- 10% | single phase 230V +/- 10% |
| No-Load Voltage (V) | 58V @ TIG 58V @ MMA | 58V @ TIG 58V @ MMA |
| Duty Cycle (%) | 60% - 200A @ TIG 25°C 60% - 170A @ MMA 25°C 40% - 200A @ TIG 40°C 40% - 170A @ MMA 40°C | 60% - 200A @ TIG 25°C 60% - 170A @ MMA 25°C 40% - 200A @ TIG 40°C 40% - 170A @ MMA 40°C |
| Electrode available | 1.6 / 2.5 / 3.2 / 4.0 mm | 1.6 / 2.5 / 3.2 / 4.0 mm |
| Power Capacity (KVA) | 7.5 KVA | 7.5 KVA |
| Dimension (cm) | 43 x 21 x 36 | 43 x 21 x 36 |
| Gross Weight (Kg) | 9 Kg | 7.5 Kg |
